Current position:PRODUCTS > Water treatment equipment >
Large Capacity Mechanical Automatic Sand Filter For Water Treatment

Large Capacity Mechanical Automatic Sand Filter For Water Treatment

Features:

Material:SUS304 / SUS316 /Q235B

Application:Water Reuse system / Pure water system

Core Components:Pressure vessel, Pump, PLC

Get Quotation

Product Details

Specification



Influent turbidity

<20FTU

Effluent turbidity

<3FTU

Sewage interception capacity

5-15Kg/m3 (filter material).

Working temperature

5-60℃ (special temperature can be customized)

Working pressure

≤0.6MPa

Inlet water pressure

≥0.04MPa

Backwash water inlet pressure

≥0.15 MPa

Pressure difference between inlet and outlet

0.01-0.015MPa

Working method

pressure type

Connections

Flange

Operation mode

water flow from top to bottom

Filtration speed

15-100m3/h

Operating cycle

2-7 days

Backwashing method

water washing, or air-water combined backwashing

Water consumption for backwashing

1-3%

Backwash intensity

4-15L/s·m2

Backwash time

5-7 minutes

Backwash expansion rate

40-50%



Features



Stainless Steel or Carbon Steel Sand Filter / Active Carbon Filter

Also called Mechanical filter

Categories:

1: Multi Media filter ,

2: Active carbon filter,

3: Quartz sand filter etc.

4. Easy to manage, low operating cost

5. Filter media durable and recyclable

6. Most practical, cheapest and basic filtration equipment



Application

Mechanical Filter (Alao called pressure filter ), It's very important procedure in pure water pretreatment  and water purify system.



In water treatment field, filtration is a kind of water purifying process.Mostly filter medias are silica sand (widely use),anthracite and so on. Filter medias include three type:granular, powdery and fibroid. Silica sand,anthracite, activated carbon, megnetite,ceramic, plastic ball, ect.

According to actual demands, some multi media filter (filter bed) will use two kinds of media layers. In industrial water recycling system, can effectively remove impurity,absorb oil ect, at last to reach

water recycling standard. Mainly functions are remove suspended or colloidal impurity, especially

effectively remove small particle and bacterium, also can remove BODs and COD in certain level.
