: Low Maintenance Water Treatment Sand Filter To Trap And Retain Larger Number Of Solid Particles

Features:

Material:SUS304 / SUS316 /Q235B

Application: Water Reuse system / Pure water system

Core Components:Pressure vessel, Pump, PLC
Get Quotation

Product Details

Specification

Influent turbidity	<20FTU
Effluent turbidity	<3FTU
Sewage interception capacity	5-15Kg/m3 (filter material).
Working temperature	5-60℃ (special temperature can be customized)
Working pressure	≤0.6MPa
Inlet water pressure	≥0.04MPa
Backwash water inlet pressure	≥0.15 MPa
Pressure difference between inlet and outlet	0.01-0.015MPa
Working method	pressure type
Connections	Flange
Operation mode	water flow from top to bottom
Filtration speed	15-100m3/h
Operating cycle	2-7 days
Backwashing method	water washing, or air-water combined backwashing
Water consumption for backwashing	1-3%
Backwash intensity	4-15L/s·m2
Backwash time	5-7 minutes
Backwash expansion rate	40-50%

Features

Stainless Steel or Carbon Steel Sand Filter / Active Carbon Filter

Also called Mechanical filter

Categories:

1: Multi Media filter ,

2: Active carbon filter,

3: Quartz sand filter etc.

4. Easy to manage, low operating cost

5. Filter media durable and recyclable

6. Most practical, cheapest and basic filtration equipment

Application

Mechanical Filter (Alao called pressure filter ), It's very important procedure in pure water pretreatment and water purify system.

In water treatment field, filtration is a kind of water purifying process.Mostly filter medias are silica sand (widely use),anthracite and so on. Filter medias include three type:granular, powdery and fibroid. Silica sand,anthracite, activated carbon, megnetite,ceramic, plastic ball, ect.

According to actual demands, some multi media filter (filter bed) will use two kinds of media layers. In industrial water recycling system, can effectively remove impurity,absorb oil ect, at last to reach

water recycling standard. Mainly functions are remove suspended or colloidal impurity, especially

effectively remove small particle and bacterium, also can remove BODs and COD in certain level.
