Product Details
Description
This machine is mainly used to deal with unqualified transformer oil, turbine oil, hydraulic oil, mechanical oil, switch oil, etc.
It can remove the gas, moisture and mechanical impurities in the oil, so that the oil is qualified for application.
The machine has the characteristics of small size, high efficiency, and convenient movement, which is especially suitable for on-site operations, and can dry the moisture of the electric equipment, and it can also conveniently carry out the vacuum oiling of the electric equipment.
This machine adopts oil-water separation technology that combines thin film vacuum evaporation and spray drying. It sets the vacuum pumping rate and heating power to match the flow rate. It is equipped with high-efficiency degassing elements, so that the machine has the best degassing and dehydration function.
This machine is specially designed with an oil level controller, an oil level observation window, and an oil return adjustment system to facilitate the observation of the oil level and ease the vacuum release as required.
Item | Unit | AOP-VS25 ~VS150 |
Flowrate | L/min | 25 ~ 150 |
Working Pressure | Mpa | ≤0.3 |
Rated Vaccum Pa | Mpa | -0.06 to -0.099 |
Break down voltage | KV | ≥ 55 ~65 |
Water Content | PPM | ≤50 |
Air Content | % | ≤0.1 |
Coarse filtration | um | 100 |
Fine filtration | um | 3 、5 |
Voltage | V | AC 380V three phase 、50Hz |
Heat power | KW | 6-15 ~ 60 |
Power | KW | 7-17 ~ 65 |
Weight | Kg | 195 ~ 700 |
Packing Dimensions | mm | 605*882*1225mm etc. |
